Cutting & Gouging Electrodes

ADGROOVE

Characteristics

An all position electrode, having special exothermic coatings which concentrate the force of the arc right at the point of application and yeilds a highly efficient metal removing tool.

Current Range & Packing Data
Size mm Dia x Length Current Range (Amps) DC(+) Kgs per Packet Kgs per Case
5.00 x 450 260 - 300 5 20
4.00 x 450 200-240 5 20
3.15 x 450 160-180 5 20

ADCUT

Characteristics

An all position electrode for cutting mild steel, cast iron etc., without a gas cutting equipment.

Current Range & Packing Data
Size mm Dia x Length Current Range (Amps) DC(+) Kgs per Packet Kgs per Case
5.00 x 450 260 - 300 5 20
4.00 x 450 200-240 5 20
3.15 x 450 160-180 5 20
