Classifications
- AWS A / SFA 5.4 : E 308 - 16
- IS 5206 : E 19.9 R26
Characteristics
AA rutile basic coated , low carbon 19 cr-10Ni stainless steel electrode with controlled ferrite. This is useful for welding non-established Cr-Ni steels of 18/8 type resistance to atmospheric corrosion. The weld metal is highly resistant to cracking , corrosion and oxidation at high temp up to 800 o C. Weld metal has excellent creep strength and is of radiographic quality.
Applications
Ideal for welding corrosion resistant to Cr-Ni steels of AISI grades 301,302,304,308 used in dairy, food processing and chemical industries etc.
Typical Weld Metal Composition
|
Element
|
Percentage
|
| C |
0.8 max |
| Mn |
0.70 - 2.00 |
| Si |
0.85 max |
| S & P |
0.030 max |
| Ni |
9.00 - 11.00 max |
| Cr |
18.00 - 21.00 |
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
Ferrite No.
|
| 550 - 650 MPa |
30 - 45 |
3 - 7 |
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140 - 170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
90-110
|
2
|
10
|
|
2.50 x 350
|
50-75
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : IF MOIST, REDRY AT 300°C FOR 1 HOURS
Classifications
- AWS A / SFA 5.4 : E 316 - 16
- IS 5206 : E 19.9 R26
Characteristics
A medium-heavy coated rutile type stainless steel electrode giving excellent creep strength and is of radiographic quality.
Applications
Ideal for welding corrosion resistant 18% Cr-8% Ni-2% Mo steels of AISI grade 316,317 used in paint industries, pharmaceutical and chemical industries.
Typical Weld Metal Composition
|
Element
|
Percentage
|
| C |
0.08 max |
| Mn |
1.0 - 2.40 |
| Si |
0.90 max |
| S & P |
0.040 max |
| Ni |
11.00 - 14.00 max |
| Cr |
17.00 - 20.00 |
| Cr |
2.00 - 3.00 |
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
Ferrite No.
|
| 530 - 640 MPa |
30 - 40 |
4 - 8 |
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140 - 170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
90-110
|
2
|
10
|
|
2.50 x 350
|
50-75
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : IF MOIST, REDRY AT 300°C FOR 1 HOURS
Classifications
- AWS A / SFA 5.4 : E 308L - 16
- IS 5206 : E 19.9 LR26
Characteristics
A semi basic type stainless steel electrode giving extra low carbon 19 cr-10 (Mi controlled ferrite weld metal. Weld arc of radiographic quality offers excellent corrosion resistance to various media. Scaling and oxidation is satisfactory and up to 800 o C.
Applications
Ideal for welding corrosion resistant Cr-IMi steels of AISI grades 301,302,304,304L,308,308L used in dairy , food processing units, Pharmaceutical and chemical industries.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.04 Max
|
|
Mn
|
1.00-1.40
|
|
Si
|
0.85 Max
|
|
S & P
|
0.030 Max
|
|
Ni
|
9.00-11.0Max
|
|
Cr
|
18.00-21.00
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
Ferrite No.
|
|
530 - 640 MPa
|
35 - 45
|
3-7
|
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140 - 170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
90-110
|
2
|
10
|
|
2.50 x 350
|
50-75
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 300°C for ½ Hours.
Classifications
- AWS A / SFA 5.4 : E 316L - 16
- IS 5206 : E 19.12.2 LR26
Characteristics
A medium-heavy coated rutile type stainless steel electrode giving 18%Cr-8%Ni-2%Mo with extra low carbon and is of radiographic quality.
Applications
Suitable for AISI 316L.,317L grade stainless steel used in chemical plants, paper industries , textile industries etc.,
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.04 Max
|
|
Mn
|
0.50 - 2.50
|
|
Si
|
0.90 Max
|
|
S & P
|
0.030 Max
|
|
Ni
|
11.00-14.00 Max
|
|
Cr
|
17.00-20.00
|
|
Mo
|
2.00-3.00
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
Ferrite No.
|
|
530 - 640 MPa
|
30-40
|
4-8
|
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC (+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140-170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
90-110
|
2
|
10
|
|
2.50 x 350
|
50-75
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 300°C for 1 Hours.
Classifications
- AWS A / SFA 5.4 : E 309 - 16
- IS 5206 : E 23.12 R26
Characteristics
A medium-heavy coated rutile type electrode producing 25Cr-12Ni deposit having excellent and oxidation resistance up to 1100 o C and gives radiographic quality weld.
Applications
For welding of AISI 309 stainless steel. Straight chrome steels,18/8 clad steels, low alloy and carbon steel etc.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.8 Max
|
|
Mn
|
1.6-2.20
|
|
Si
|
0.80 Max
|
|
S & P
|
0.030 Max
|
|
Ni
|
12.00-14.00 Max
|
|
Cr
|
23.00-25.00
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
Ferrite No.
|
|
550 - 650 MPa
|
30-45
|
12-15
|
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC (+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140-170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
90-110
|
2
|
10
|
|
2.50 x 350
|
50-75
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 300°C for 1 Hours.
Classifications
- AWS A / SFA 5.4 : E 309 Mo - 16
- IS 5206 : E 23.12.2 R26
Characteristics
A medium heavy coated rutile type all position electrode producing 25 Cr-12Ni-2 Mo deposit having resistance to chemical corrosion and heat resistance up to 1100°C
Applications
For welding of AISI 309 Mo stainless steel, straight chrome steels,18/8 clad steels, low alloy and carbon steel etc.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.8 Max
|
|
Mn
|
1.60-2.10
|
|
Si
|
0.90 Max
|
|
S & P
|
0.030 Max
|
|
Ni
|
12.00-14.00 Max
|
|
Cr
|
22.00-25.00
|
|
Mo
|
2.00-3.00
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
Ferrite No.
|
|
590 - 700 MPa
|
30-40
|
12-15
|
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC (+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140-170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
90-110
|
2
|
10
|
|
2.50 x 350
|
50-75
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 300°C for 1 Hours.
Classifications
- AWS A / SFA 5.4 : E 310 - 16
- IS 5206 : E 25.20 R26
Characteristics
A medium-heavy coated rutile type all position stainless steel electrode with excellent welding equipments characteristics. The weld metal gives 25% chromium 20% nickel deposit, excellent resistance to oxidation, scaling up to 1200° C and is of radiographic quality.
Applications
Suitable for welding of AISI 310 grades plates, German steel grades 4762,4828,4846 & 4848, straight chromium steel, dissimilar steels, high temperature furnace parts annealing boxes etc.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.13 Max
|
|
Mn
|
1.00 - 2.50
|
|
Si
|
0.80 Max
|
|
S & P
|
0.030 Max
|
|
Ni
|
20.00-25.00 Max
|
|
Cr
|
25.00-28.00
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
|
560 - 660 MPa
|
30-40
|
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC (+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140-170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
90-110
|
2
|
10
|
|
2.50 x 350
|
50-75
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 300°C for 1 Hours.
Classifications
- AWS A / SFA 5.4 : E 312 - 16
- IS 5206 : E 29.9 R26
Characteristics
A medium-heavy coated rutile type all position stainless steel electrode with excellent welding characteristics. The weld metal gives 30% chromium 10 % nickel deposit, excellent resistance to friction, heat, corrosion and is of radiographic quality.
Applications
Welding and surfacing of tool steel, spring steel, high speed steel, case hardening steel , manganese steel, heavy machine parts and earth moving equipment parts, dissimilar joints between stainless and carbon steels etc.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.15 Max
|
|
Mn
|
0.60 - 2.40
|
|
Si
|
1.00 Max
|
|
S & P
|
0.030 Max
|
|
Ni
|
8.00-10.00 Max
|
|
Cr
|
28.00-32.00
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
|
690 - 850 MPa
|
21-23
|
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC (+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
140-170
|
2
|
10
|
|
4.00 x 350
|
110-140
|
2
|
10
|
|
3.15 x 350
|
80-110
|
2
|
10
|
|
2.50 x 350
|
35-50
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 300°C for 1 Hours.
Classifications
- AWS A / SFA 5.4 : E 410 - 15
Characteristics
A medium-heavy coated hydrogen controlled stainless steel electrode giving 13% Chromium. The weld metal is of radiographic quality, resistant to friction, corrosion and oxidation and air hardenable. Use Ofpre-heat and stress relieve is strongly recommended to avoid hardening in the weld zone.
Applications
Ideal for welding and surfacing of 13% chromium Steel, ferrite martens tic stainless steel, turbines, armature, valves arid pumps.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.10 Max
|
|
Mn
|
0.50 - 1.00
|
|
Si
|
0.70 Max
|
|
S & P
|
0.040 Max
|
|
Ni
|
0.50-0.70
|
|
Cr
|
11.00-13.50
|
|
Mo
|
0.20-0.60
|
|
Cu
|
0.40-0.60
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Elongation % (L=4d)
|
|
520 - 600 MPa
|
15-25
|
Current Range & Packing Data
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC (+)
|
Kgs per Packet
|
Kgs per Case
|
|
5.00 x 350
|
160-220
|
2
|
10
|
|
4.00 x 350
|
110-150
|
2
|
10
|
|
3.15 x 350
|
90-120
|
2
|
10
|
|
2.50 x 350
|
50-80
|
2
|
10
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 300°C for 1 Hours.
