Classifications
- AWS A / SFA 5.1 : E 6013
- IS 814 : E R 4211
- Approved By : BIS
Characteristics
A rutile type light-medium coated electrode for welding light and medium fabrications.
Gives smooth arc action, Self Lifting Slag, Least Spatter , finely rippled , Radiographic
Quality and all position welding.
Applications
Suitable for all types of mild steel structures, tank and vessels, general fabrication,
vehicles, railway coaches, Wagons, Ship hull, Boilers and joining steels like A,B,C,D
grades of ASTM SA-283.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.10 Max
|
|
Mn
|
0.30 - 0.60
|
|
Si
|
0.25 Max
|
|
P
|
0.030 Max
|
|
S
|
0.030 Max
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Yield Strength
|
Elongation % (L=4d)
|
Charpy Impact Value at +27°C
|
|
410 - 580 MPa
|
370 - 480 MPa
|
22 - 30
|
40 - 60 J
|
Typical Mechanical Properties of all Weld Metal
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(-)
|
Pieces per Packet
|
Pieces per Case
|
|
5.00 x 450
|
170 - 220
|
40
|
240
|
|
4.00 x 450
|
140-170
|
60
|
360
|
|
3.15 x 450
|
90-110
|
90
|
540
|
|
3.15 x 350
|
90-120
|
90
|
540
|
|
2.50 x 350
|
60-80
|
125
|
750
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 100°C for ½ Hours.
Classifications
Characteristics
A rutile type light-medium coated electrode for welding light and medium fabrications.
Gives smooth arc action, Self Lifting Slag, Least Spatter , finely rippled , Radiographic
Quality and all position welding.
Applications
Suitable for all types of mild steel structures, tank and vessels, general fabrication,
vehicles, railway coaches, Wagons, Ship hull, Boilers and joining steels like A,B,C,D
grades of ASTM SA-283.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.12 Max
|
|
Mn
|
0.25 - 0.50
|
|
Si
|
0.30 Max
|
|
P
|
0.030 Max
|
|
S
|
0.030 Max
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Yield Strength
|
Elongation % (L=4d)
|
Charpy Impact Value at +27°C
|
|
450 - 580 MPa
|
350 - 480 MPa
|
17 - 25
|
40 - 60 J
|
Typical Mechanical Properties of all Weld Metal
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(-)
|
Pieces per Packet
|
Pieces per Case
|
|
5.00 x 450
|
170 - 220
|
40
|
240
|
|
4.00 x 450
|
140-170
|
60
|
360
|
|
3.15 x 350
|
90-120
|
90
|
540
|
|
2.50 x 350
|
60-80
|
125
|
750
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 100°C for ½ Hours.
Classifications
- AWS A / SFA 5.1 : E 6013
- IS 814 : E R 4211X
Characteristics
A rutile type light-medium coated electrode for welding light and medium fabrications.
Gives smooth arc action, Self Lifting Slag, Least Spatter , finely rippled , Radiographic
Quality and all position welding.
Applications
Suitable for all types of mild steel structures, tank and vessels, general fabrication,
vehicles, railway coaches, Wagons, Ship hull, Boilers and joining steels like A,B,C,D
grades of ASTM SA-283.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.10 Max
|
|
Mn
|
0.30 - 0.60
|
|
Si
|
0.25 Max
|
|
P
|
0.030 Max
|
|
S
|
0.030 Max
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Yield Strength
|
Elongation % (L=4d)
|
Charpy Impact Value at +27°C
|
|
410 - 580 MPa
|
370 - 480 MPa
|
22 - 30
|
40 - 60 J
|
Typical Mechanical Properties of all Weld Metal
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(-)
|
Pieces per Packet
|
Pieces per Case
|
|
5.00 x 450
|
170 - 220
|
40
|
240
|
|
4.00 x 450
|
140-170
|
60
|
360
|
|
3.15 x 450
|
90-110
|
90
|
540
|
|
3.15 x 350
|
90-120
|
90
|
540
|
|
2.50 x 350
|
60-80
|
125
|
750
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 100°C for ½ Hours.
Classifications
- AWS A / SFA 5.1 : E 6013
- IS 814 : E R 4222 X
Characteristics
A medium-heavy coated rutile type of all position welding electrode, specially designed for radiographic quality weld .Low spatter, easy slag removal, adequate penetration and smooth bead are the special feature of this electrode. This electrode can be operated without maintaining an arc gap and suitable for vertical and overhead welding. Weld deposit possesses good chemical and mechanical properties.
Applications
Suitable for all types of mild steel structure, tank and vessels, general fabricator, vehicles, railway coaches, Wagons, Ship hull, Boilers, Pressure pipelines which cannot be welded from inside, construction equipments and joining steels like ASTM SA - 36 / SA 36M, A,B,C,D grades of SA-283/ SA 283 M, A,B,C grades of SA-285/SA 285 M, A,B grades of SA 414/SA 414 M.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.10 Max
|
|
Mn
|
0.40 - 0.60
|
|
Si
|
0.25 Max
|
|
P
|
0.030 Max
|
|
S
|
0.030 Max
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Yield Strength
|
Elongation % (L=4d)
|
Charpy Impact Value at +27°C
|
|
460 - 550 MPa
|
370 - 480 MPa
|
22 - 30
|
40 - 60 J
|
Typical Mechanical Properties of all Weld Metal
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(-)
|
Pieces per Packet
|
Pieces per Case
|
|
5.00 x 450
|
160 - 250
|
55
|
220
|
|
4.00 x 450
|
120-190
|
85
|
340
|
|
3.15 x 450
|
80-140
|
130
|
520
|
|
3.15 x 350
|
80-140
|
130
|
520
|
|
2.50 x 350
|
60-90
|
280
|
1120
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 100°C for ½ Hours.
Classifications
- AWS A / SFA 5.1 : E 6013
- IS 814 : E RR 4222 X
Characteristics
A heavy coated rutile type for achieving weld of superior finish and radiographic quality. Gives low spatter and excellent self peeling slag. Striking and re-striking is excellent. It has very quiet and stable arc during welding performances with exceptionally clean and smooth bead.
Applications
Suitable for pressure vessels, boilers, locomotive fire boxes, bridges, auto frames, railway coaches and thin steel due to its droplet transfer and joining of steels like A, B, C grades SA 285/ SA 285 M, A,B grades of SA 414/ SA 414 M.
Typical Weld Metal Composition
|
Element
|
Percentage
|
|
C
|
0.10 Max
|
|
Mn
|
0.40 - 0.60
|
|
Si
|
0.28 Max
|
|
P
|
0.030 Max
|
|
S
|
0.030 Max
|
Typical Mechanical Properties of all Weld Metal
|
Tensile Strength
|
Yield Strength
|
Elongation % (L=4d)
|
Charpy Impact Value at +27°C
|
|
460 - 550 MPa
|
360 - 480 MPa
|
24 - 30
|
50 - 80 J
|
Typical Mechanical Properties of all Weld Metal
|
Size mm Dia x Length
|
Current Range (Amps) AC / DC(-)
|
Pieces per Packet
|
Pieces per Case
|
|
5.00 x 450
|
190 - 250
|
50
|
200
|
|
4.00 x 450
|
140-190
|
75
|
300
|
|
3.15 x 450
|
100-140
|
115
|
460
|
|
3.15 x 350
|
100-140
|
115
|
460
|
|
2.50 x 350
|
60-100
|
245
|
980
|
- Welding Positions: F,H, V-UP, OH
- Re-drying Conditions : If Moist, Re-dry at 100°C for ½ Hours.
